5Pcs Dc5-120V 0.56" 2 Wire Led Digital Display Panel Voltmeter Volt Tester Blue

In stock
SKU: I018-A016-Blu
Regular price £7.89 GBP
Color

Feature:
1: The range of the voltmeter is 5-120V. It adopts a 2-wire system with a wire length of 20cm.
2: It can be directly connected to the power supply terminal to display the current power supply voltage.
3: This Voltmeter has a function for reverse protection.
4: The working current is less than 20mA, the heat is low, and the efficiency is high.
5: Durable and safety. Small size and lightweight, easy to carry.
6: The decimal point is automatically shifted, 2 decimal points are displayed below 10V, decimal points are displayed between 10-100V, and there is no decimal point above 100V.
7: Applications: Voltage display for batteries, electric vehicles, medical equipment, power generation systems, solar energy and other products.

Specifics:
Condition: 100% Brand New
Measurement Range: DC5V ~ 120V (Blue/Red/Green)
Working voltage: DC5V ~ 120V (Blue/Red/Green)
High input: DC132V (input voltage higher than 132V may be permanently damaged!)
Display: 0.56 inch LED
Measurement rate: ≥300mS / times
Allowable Error: ±1%
Input Impedance: >100KΩ
Working Current: Red <23mA, Green <18mA, Blue <13mA
Working temperature :-20 ~ +65℃
Lead Length: 20 cm / 7.87 inches(Approx.)
External Dimensions: 4.8 * 2.9 * 2.2 cm / 1.89 * 1.17 * 0.87 inches(Approx.)
Hole Size: 4.6 * 2.7 cm / 1.81 * 1.06 inches(Approx.)
Weight: 25g/pc

Note:
1.Please allow 1-3mm difference due to manual measurement.
2.Please check and confirm the package content and the price before buying.

Package Included:
5 X Mini Dc 5-120V Led Voltmeter
