Description:
1. The industrial-grade master control chip, AD sampling precision, temperature, level 16 charging current, discharge current, the cumulative output real-time display, screen shows at the same time, be clear at a glance.
2.Automatic focusing MPPT tracking charging, high charging efficiency, non-stop detection during charging, bidirectional focusing tracking.
3.large-screen LCD display, adjustable charging and discharging parameters. Ultra-wide charge and discharge adjustable, as long as you understand the characteristics of the battery set its corresponding charging parameters, you can charge a battery. When the output is off, the time can be adjusted, which is more convenient (on the market, there is no point adjustment).
4.a complete three-phase charge management, effectively protect the battery, the battery is more durable.
5. built-in overheating, overcurrent, short circuit, open circuit protection, reverse connection protection, when the fault is eliminated, the controller automatically recovers, does not damage the device.
6.bidirectional MOS tube anti-backflow circuit, high-power charging mode, ultra-low heat.

Features:
●Current focusing MPPT charging
●Mobile Bluetooth APP control
●Displays voltage, charge, discharge, current, temperature and cumulative power generation
●Rechargeable lithium battery/solid battery/lead-acid, lithium iron phosphate battery
●Supports 12/24V and 12/24V/36V/48V/60V batteries
●Lightweight and efficient
●Terminal lug for high current thick wire access
●Flip-top gold or steel blue looks exquisite
●30A\40A\50A iron plate
●60A aluminum plate

MPPT Gold
Specifications:
Type: MPPT Controller
Color: Gold
System Voltage:12V/24V
Rated Charge Current: 30A/40A/50A/60A
Rated Discharge Current: 15A/15A/20A/25A
Self-Consume: <10mA
USB Output: 5V/2A Max
Operating Temperature: -10-+60℃
Siez/Weight : 133×70×35mm/150g

MPPT Blue
Specifications:
Type: MPPT Controller
Color: Blue
System Voltage:12/24V/36V/48V/60V
Rated Charge Current: 30A/40A/50A/60A
Rated Discharge Current: 15A/15A/20A/25A
Self-Consume: <10mA
USB Output: 5V/2A Max
Operating Temperature: -10-+60℃
Siez/Weight : 133×70×35mm/150g

Package Included:
1 * Solar controller unit
1 * Detailed User manual
